Pumps

Auto Back Pressure Regulator

Material: SS

Auto BPR BP-11 SeriesAuto Back Pressure Regulator for the UI-22 SeriesAutomatic Pressure RegulationFeaturesProvide consistent pressure by tracking variable pump pressure in real timeUI Series provides stable flow, BP-11 maintains set pressure Part numberBP-11SBP-11D Wetted materialsSUS , PFAPCTFE , PFA Path diameter0.6 mm Pressure range0.10 - 5.00 MPa (14.5 - 725 psi) Flow rate range0.1 - 100 mL/mi Pressure range*10.5 - 5.00 MPa (72.5 - 725 psi) Pressure accuracy±,0.1 MPa (±,14.5 psi) Pressure signal rangeuses pressure signal from UI-22 [ DC1 - 5V ] FeaturesSet volume dispensing*3, Set volume dispensing*4, Upper/lower pressure limiters CommunicationRS232C, RS485 (START-IN, READY-OUT) Dimensions144 (H) ×, 79 (W) ×, 240 (D) mm, excluding protuberances WeightApprox. 2.7 kg PowerAC100 - 240 V (50 / 60 Hz) MAX 70 VA *1: Using distilled water or methanol, pressure 0.5~5.0MPa / flow rate 0.1~50.0mL/min are controllable.※: please contact us if you need flow rates outside 0.1~50.0mL/mi.

€3,200.00*

Dual pump (with pressure sensor)

Pressure Sensor: With | Material: PEEK | Max. Flow Rate: 1 mL/min. | Max. Pressure: 20 MPa / 2900 psi

Dual Pump KP-21 SeriesDual Plunger PumpA general use pump equipped without pressure sensorFeaturesCam-driven design with high flow accuracy and low pulsingPressure sensor allows setting upper/lower limits6 separate configurations of flow range/pumphead materialRS232C control protocol Part numberKP-21-01SKP-21-01PKP-21-13SKP-21-13PKP-21-33SKP-21-33P Pumphead materialSUSPEEKSUSPEEKSUSPEEK Max pressure*125 MPa (3625 psi)20 MPa (2900 psi)25 MPa (3625 psi)20 MPa (2900 psi)5 MPa (725 psi) Flow rate range*20.001 - 1.000 mL/min0.01 - 10.00 mL/min0.1 ~ 50.0 mL/min Flow per stroke4 µL32 µL154 µL Plunger stroke1 mm4 mm Flow accuracy< 0.3 % FeaturesSet volume dispensing*3 Pressure accuracy- Wetted materialsSUS:Sapphire, Ruby, PTFE, PCTFE, PFA, ETFE, FFKM, HDPE, PEEK, SUS PEEK:Sapphire, Ruby, PTFE, PCTFE, PFA, ETFE, FFKM, HDPE PEEK Remote controlInput:PUMP ON / OFF, Output:Error signal CommunicationRS232C Dimensions144 (H) ×, 79 (W) ×, 285 (D) mm, excluding protuberances WeightApprox. 4.3 kg PowerAC100 - 240 V (50 / 60 Hz) MAX 80 VA *1: Maximum pressure is only sustained intermittently. Continuous pump operation at maximum pressure cannot be guaranteed.*2: The unit cannot run continuously at maximum flow rate.*3: In set volume mode, when the set volume has been dispensed, pumping automatically stops.

Variants from €3,200.00*

€4,900.00*

High Pressure Damper

Product name: High Pressure DamperPart number: 9810Max pressure: 20 MPa (2900 psi)Pulse control range: 8-12 MPa (1160-1740 psi)Internal volume: Approx. 3.5 mLWetter material PEEK, PTFEThread size: No.10-32 UNFDimensions: φ50mm × 36.5(D)mmWeight: Approx. 0.3 kgOrder Code: PDM-F001

€540.00*

Intelligent Micro pump

Intelligent Micro Pump MP-22Valve Switching Micro PumpCheck valve-less design for super lowpulse control under low flow ratesFeaturesImproved near-zero pulse flowProblems with bubble greatly reducedEasy setupUpper and lower pressure limitersSpace-saving compact designExternal control available with RS232C protocol Part numberMP-22-110S Pumphead materialSUS Max pressure*35 MPa (5075 psi) Flow rate range**0.001 - 9.999 mL/min Flow per stroke80 µL Plunger stroke10 mm Flow accuracy***< 0.3 % FeaturesActive pulse reduction, upper/lower pressure limiters Pressure accuracy< 5 % Wetted materialsSapphire, Ruby, PTFE, PCTFE, PFA, ETFE, FFKM, HDPE, PEEK, SUS Remote controlInput:PUMP ON / OFF, Output:Error signal CommunicationRS232C, RS485(between FLOM devices) Dimensions150 (H) ×, 160 (W) ×, 280 (D) mm, excluding protuberances WeightApprox. 6.7 kg PowerAC100 - 240 V (50 / 60 Hz) MAX 140 VA *: Maximum pressure is only sustained intermittently.**: Maximum output is not sustainable over long periods of time.***: Using Methanol at flow rate10~500&mu,L/min , output pressure >, 1 MPa ~ 20MPa

€7,900.00*

Intelligent pump PEEK 80 μL

Material: PEEK | Max. Flow Rate: 10 mL/min. | Max. Pressure: 20 MPa / 2900 psi

Intelligent Pump UI-22 SeriesLinear Motor Pulse Control Intelligent PumpCombines high precision flow and ease of useFeaturesPulses reduced to absolute minimum making low flow rate pumping possibleBubble problems greatly reducedLong life plunger sealUpper and lower pressure limitersSpace-saving compact designControl with RS232C protocolChoose SUS, PEEK, or PCTFE to fit your solvent Part numberUI-22-110SUI-22-110PUI-22-110DUI-22-410SUI-22-410PUI-22-410D Pumphead materialSUSPEEKPCTFESUSPEEKPCTFE Max pressure*35 MPa (5075 psi)20 MPa (2900 psi)2 MPa (290 psi)5 MPa (725 psi)5 MPa (725 psi)2 MPa (290 psi) Flow rate range**0.001 - 9.999 mL/min0.01 - 99.99 mL/min Flow per stroke80 μL708 μL Plunger stroke10 mm Flow accuracy<, 0.3 % FeaturesActive pulse reduction, upper/lower pressure limiters Pressure accuracy<, 5 % Wetted materialsSUS: Sapphire, Ruby, PTFE, PCTFE, PFA, FFKM, HDPE, PEEK, SUS PEEK: Sapphire, Ruby, PTFE, PCTFE, PFA, ETFE, FFKM, HDPE, PEEK PCTFE: Sapphire, Ruby, PTFE, PCTFE, PFA, ETFE, FFKM Remote controlInput:PUMP ON / OFF, Output:Error signal CommunicationRS232C , RS485(between FLOM devices) Dimensions144 (H) × 105 (W) × 240 (D) mm, excluding protuberances WeightApprox. 5.6 kg PowerAC100 - 240 V(50 / 60 Hz) MAX140 VA *: Maximum pressure is only sustained intermittently.**: Maximum output is not sustainable over long periods of time.

€4,300.00*

Low Pressure Damper

Product name: Low Pressure DamperPart number: 9800Max pressure: 2 MPa (290 psi)Pulse control range: 0.1~0.7 MPa (14.5-101.5 psi)Internal volume: Approx. 0.8 mLWetter material: PEEK, FEPThread size: No.10-32 UNFDimensions: φ45mm × 33(D)mmWeight: Approx. 0.3 kgOrder Code: PDM-F002

€540.00*

Roller pump

Roller Pump WP-21Roller PumpGreat for plunger pump cleaning and basic pumping applicationsFeaturesSpace-saving compact designChoose tubing to match your solventTube cassette can be set in any of 4 directions&nbsp, Part numberWP-21 Flow rate range4 step settings (approx. 0.5・1.0・2.0・3.0 ml/min) Switching4 steps from front switch(rotary style) Featureshold down front switch to purge(approx. 5 mL/min) Flow accuracy&plusmn, 5 % (Pharmed BPT) Output pressure90 kpa or less (Pharmed BPT) Intake pressure-90 kpa or less (Pharmed BPT) Temperature range5 - 50 &deg,C Rotary directionClockwise when viewed from front External I/O Input:OFF/ ON switch (powering on begins pumping)Output:Error Signal TubingPharmed BPT / Fluran F-5500-A / TransMaster TM-15 Dimensions65 (H) &times, 46 (W) &times, 110 (D) mm, excluding protuberances WeightApprox. 0.5 kg PowerAC100 - 240 V(50 / 60 Hz)MAX 15 W Product comes with Pharmed BPT tubing standard.Please contact us if you prefer Fluran F-5500-A or TransMaster TM-15 tubing.&nbsp, &nbsp,Pumping action begins automatically as soon as the power is turned on.

€640.00*

Side Panel for Valve Attachment

€150.00*

Side Panel for Valve Attachment

€150.00*

Side Panel for Valve Attachment

Product name: Side PanelPart number: 4512Pump type: UI-22, KP-2x, SP-2x SeriesAttachable parts: VI-11, VI-12, MI-11, V05Damper attachable: NoDimensions: 144 (H) × 60 (W) × 44 (D) mm, excluding protuberancesOrder code: PB1001-10

€150.00*

Single Plunger Pump (with Pressure Sensor)

Pressure Sensor: With | Material: PEEK | Max. Flow Rate: 20 mL/min. | Max. Pressure: 2 MPa / 290 psi

PCS Pump SP-21 SeriesSingle Plunger PumpSingle plunger pump without pressure sensorFeaturesCan choose Quick Return mode for Pulse ControlReasnable price without equipping pressure sensor10 separate configurations of flow range/pumphead materialRS232C control protocolPart numberSP-21-02SSP-21-02PSP-21-12SSP-21-12PSP-21-13SSP-21-13PSP-21-32PSP-21-32PSP-21-33PSP-21-33PPumphead materialSUSPEEKSUSPEEKSUSPEEKSUSPEEKSUSPEEKMax pressure*120 MPa (2900 psi)10 MPa (1450 psi)5 MPa (725 psi)2 MPa (290 psi)Flow rate range*20.001 ~ 1.000 mL/min0.01 - 2.00 mL/min0.1 - 5.0 mL/min0.1 - 10.0 mL/min0.1 - 20.0 mL/minFlow per stroke8 µL16 µL32 µL77 µL154 µLPlunger stroke2 mm4 mm2 mm4 mmFlow accuracy±, 0.5 %FeaturesSet volume dispensing*3Pressure accuracy-Wetted materialsSUS:Sapphire, Ruby, PTFE, PCTFE, PFA, ETFE, FFKM, HDPE, SUSPEEK:Sapphire, Ruby, PTFE, PCTFE, PFA, ETFE, FFKM, HDPE, PEEKRemote controlInput:PUMP ON / OFF, Output:Error signalCommunicationRS232CDimensions144 (H) ×, 79 (W) ×, 285 (D) mm, excluding protuberancesWeightApprox. 3.0 kgPowerAC100 - 240 V (50 / 60 Hz) MAX 80 VA*1: Maximum pressure is only sustained intermittently. Continuous pump operation at maximum pressure cannot be guaranteed.*2: The unit cannot run continuously at maximum flow rate.*3: In set volume dispensing mode, when the set volume has been dispensed, pumping automatically stops.

Variants from €2,400.00*

€2,600.00*
